Storage

filex doesn't store files itself — it mounts one or more storage backends and presents them as a unified tree. Each mounted storage shows up as a top‑level folder you name. You can mix several at once (e.g. a local disk, an S3 bucket, and an SFTP server side by side).

Supported adapters: local filesystem · S3 / S3‑compatible · SFTP · WebDAV · FTP/FTPS.

• How storages work
• Adding a storage
• The storage config
• Adapters — local · S3 · SFTP · WebDAV · FTP
• Sync — staying in step with the backend
• Read‑only mounts
• Path validation & errors

---

How storages work

A storage is a row in filex's database, not an environment variable. It records the adapter (driver), a per‑adapter config blob (bucket, host, credentials, …), a mount name, and options like read‑only and sync cadence.

filex keeps a DB cache of the file tree so listings are fast (a few ms) instead of hitting the backend every time. A background sync worker keeps that cache in step with the real backend (see Sync).

Root‑path guard. A storage must point at a sub‑folder / prefix, never the bucket or filesystem root. This stops filex from ever shadowing pre‑existing objects at the root. See Path validation.

---

Adding a storage

Three equivalent ways. The admin UI is recommended — it validates the path and offers a "Test connection" before saving.

Admin UI

Sign in as an admin → Storages → Add. Pick a driver, fill in the config fields, click Test connection, then Save. The first sync starts automatically.

Admin API

POST /api/admin/storages (admin session/token). Body is the storage config; config holds the per‑adapter map:

curl -X POST https://files.example.com/api/admin/storages \
  -H 'Content-Type: application/json' -b cookies.txt \
  -d '{
    "name": "team-bucket",
    "driver": "s3",
    "mount_path": "/",
    "config": { "bucket": "my-bucket", "prefix": "filex", "region": "auto",
                "endpoint": "https://s3.example.com", "path_style": true,
                "access_key": "…", "secret_key": "…" },
    "read_only": false,
    "enabled": true
  }'

Test credentials without saving first: POST /api/admin/storages/test with the same body → {ok, sample_listing, object_count} or {ok:false, error:"…"} (the driver's error, verbatim).

CLI

Good for automation / first boot:

filex storage add \
  --name team-bucket --driver s3 --mount / \
  --config '{"bucket":"my-bucket","prefix":"filex","region":"auto",
             "endpoint":"https://s3.example.com","path_style":true,
             "access_key":"…","secret_key":"…"}'

filex storage list
filex storage remove --name team-bucket

⚠ filex storage add does not validate the root‑path guard (the API/UI do). Always give a non‑empty prefix/root/path — never /.

Connect a storage at install time (env / Compose / Helm)

You don't have to open the admin UI at all. A fresh install can come up with a storage already mounted, seeded from environment on first boot only, when no storage exists yet. The seed becomes a normal storage row you can edit afterwards; changing the env later never re‑seeds. Leaving the driver empty seeds nothing.

The variables (see CONFIGURATION.md):

Variable	For	Example
FILEX_DEFAULT_STORAGE_DRIVER	all	local · s3 · sftp · webdav · ftp
FILEX_DEFAULT_STORAGE_NAME	all	Files (top‑level folder label)
FILEX_DEFAULT_STORAGE_PATH	local	/srv/files
FILEX_DEFAULT_STORAGE_S3_* (BUCKET/PREFIX/ENDPOINT/REGION/ACCESS_KEY/SECRET_KEY/PATH_STYLE)	s3	see below
FILEX_DEFAULT_STORAGE_CONFIG	any driver	one line of the driver's config JSON

Use the dedicated vars for local and S3. To connect any other existing external storage (sftp / webdav / ftp), set the driver name and put its config JSON in FILEX_DEFAULT_STORAGE_CONFIG.

Plain binary / systemd / docker run — set env directly:

# an existing S3 bucket (AWS / Hetzner / R2 / Backblaze)
FILEX_DEFAULT_STORAGE_DRIVER=s3
FILEX_DEFAULT_STORAGE_S3_BUCKET=my-bucket
FILEX_DEFAULT_STORAGE_S3_PREFIX=filex
FILEX_DEFAULT_STORAGE_S3_REGION=eu-central-1
FILEX_DEFAULT_STORAGE_S3_ACCESS_KEY=AKIA...
FILEX_DEFAULT_STORAGE_S3_SECRET_KEY=...

# an existing SFTP / NAS server (any driver → one JSON line)
FILEX_DEFAULT_STORAGE_DRIVER=sftp
FILEX_DEFAULT_STORAGE_CONFIG={"host":"nas.example.com","port":22,"user":"filex","password":"s3cret","root":"/srv/files"}

Docker Compose — put the same vars in .env. The shipped deploy/compose/.env.example has ready copy‑paste blocks for MinIO, an external S3 bucket, SFTP and WebDAV.

Helm — set them under storage: in your values (deploy/helm/filex/values.yaml):

# an existing S3 bucket
storage:
  type: s3
  s3:
    bucket: my-bucket
    prefix: filex
    region: eu-central-1
    endpoint: "https://s3.eu-central-1.amazonaws.com"
    accessKey: "AKIA..."
    secretKey: "..."

# an existing SFTP / NAS — any driver via `config`
storage:
  type: sftp
  name: NAS
  config:
    host: nas.example.com
    port: 22
    user: filex
    password: "s3cret"
    root: /srv/files

---

The storage config

Field	Type	Default	Meaning
name	string	—	Display name + top‑level folder label. Required.
driver	string	—	local · s3 · sftp · webdav · ftp. Required.
config	object	{}	Per‑adapter settings (see Adapters).
mount_path	string	/	Logical mount point inside filex.
sync_mode	string	poll	poll · fsnotify (local only) · ondemand.
sync_interval_s	int (seconds)	900	Poll cadence. Values < 5 s are clamped to 15 min.
enabled	bool	true	Disabled storages are hidden and not synced.
read_only	bool	false	Block all writes to this mount.
rbac_enabled	bool	false	When true, per‑user RBAC grants gate access; when false the storage is visible to all authenticated users.

---

Adapters

Each adapter's config object is passed verbatim to the driver. Only the keys below are read; unknown keys are ignored.

local

Serves a directory on the host running filex.

key	required	default	notes
path	yes*	—	Absolute path to serve. Created (0755) if missing.
root	yes*	—	Legacy alias for path.

*One of path / root. Example: {"path": "/data/files"}. Capabilities: read, write, move, copy, delete, mkdir, live change events (fsnotify). Path traversal (..) is rejected.

S3 / S3‑compatible

Works with AWS S3, MinIO, Cloudflare R2, Backblaze B2 (S3), Hetzner Object Storage / Ceph RGW, and other S3‑compatible stores.

key	required	default	notes
bucket	yes	—	Bucket name.
prefix	recommended	""	Key prefix = the storage root. Must be non‑empty (root guard).
region	no	auto	e.g. us-east-1. auto suits R2/MinIO.
endpoint	no	—	Custom endpoint for non‑AWS (e.g. https://minio.example.com). Omit for AWS.
path_style	no	auto	Path‑style addressing. Auto‑enabled when endpoint is set (MinIO/Hetzner/B2/R2 need it); AWS stays virtual‑host.
access_key	no	—	Static key. If omitted, the AWS default credential chain is used (env/IRSA/instance role).
secret_key	no	—	Static secret (with access_key).
disable_presign	no	false	Force filex to stream downloads itself instead of issuing presigned URLs.

Examples

// AWS
{ "bucket": "my-bucket", "prefix": "filex", "region": "eu-central-1",
  "access_key": "AKIA…", "secret_key": "…" }

// MinIO / self-hosted
{ "bucket": "my-bucket", "prefix": "filex", "region": "auto",
  "endpoint": "https://minio.example.com", "path_style": true,
  "access_key": "…", "secret_key": "…" }

// Cloudflare R2
{ "bucket": "my-bucket", "prefix": "filex", "region": "auto",
  "endpoint": "https://<account>.r2.cloudflarestorage.com",
  "access_key": "…", "secret_key": "…" }

Gotchas & failure modes

• Hetzner Object Storage / Ceph RGW reject some AWS‑SDK presigned URLs with SignatureDoesNotMatch. If downloads fail there, set "disable_presign": true — filex then streams the bytes itself.
• Empty folders are represented by a hidden .empty marker object (created on mkdir, hidden from listings). Folder move/delete/copy recurse the prefix, so deleting or renaming a folder works even though S3 has no real directories.
• Filenames with spaces or non‑ASCII characters are fully supported (the copy source is URL‑encoded).
• bucket missing → the storage won't initialize (Test connection shows the error). Wrong keys/endpoint → Test connection fails with the SDK error.

SFTP

key	required	default	notes
host	yes	—	Server hostname/IP.
user	yes	—	SSH username.
password	one‑of	—	Password auth.
private_key	one‑of	—	PEM private key (string). Use instead of / with password.
port	no	22	Integer.
root	no	/	Base directory (use a sub‑folder).
known_hosts	no	~/.filex/known_hosts	Strict OpenSSH known_hosts path.
host_key	no	—	Pin a single host key.
insecure_skip_host_key	no	false	Disable host‑key checking (not recommended).

Provide either password or private_key. Host‑key handling: if you don't pin a key or supply a known_hosts file, filex uses trust‑on‑first‑use — it records the server key on first connect and refuses if it later changes (a MITM signal). Example: {"host":"sftp.example.com","user":"filex","private_key":"-----BEGIN OPENSSH PRIVATE KEY-----\n…","root":"/srv/files"}.

WebDAV

Tested against Nextcloud, ownCloud, Apache mod_dav, nginx‑dav, SabreDAV.

key	required	default	notes
url	yes	—	Full WebDAV base URL (scope the path here — there is no separate root).
user	yes	—	Basic‑auth user.
password	no	—	Basic‑auth password.

Only Basic auth is supported today (Bearer is planned). Example: {"url":"https://cloud.example.com/remote.php/dav/files/alice/filex","user":"alice","password":"…"}. MKCOL/MOVE/COPY/DELETE/PROPFIND back the file operations.

FTP / FTPS

key	required	default	notes
host	yes	—	Server hostname/IP.
user	yes	—	Username.
password	yes	—	Password (required, unlike SFTP).
port	no	21	Integer.
root	no	/	Base directory (use a sub‑folder).
tls	no	false	Explicit FTPS (AUTH TLS).
passive	no	true	PASV mode; set false to disable.

FTP uses a single serialized control connection, so it's the slowest adapter and copies stream through a temporary file. Prefer SFTP where possible. {"host":"ftp.example.com","user":"filex","password":"…","root":"/files","tls":true}.

---

Sync

filex serves listings from its DB cache, so it periodically reconciles that cache with the real backend to catch changes made outside filex (e.g. a file uploaded straight to the S3 console).

Modes (sync_mode):

• poll (default) — a full recursive walk every sync_interval_s seconds. Intervals below 5 s are clamped to 15 minutes.
• fsnotify — real‑time OS watch, local driver only (falls back to poll otherwise). 2‑second debounce coalesces bursts like tar -xf.
• ondemand — only syncs when explicitly triggered (POST /api/admin/storages/{id}/sync).

What a sync does: new objects are indexed, changed objects (by ETag diff) are updated, and objects gone from the backend are soft‑deleted from the cache. A tombstone guard protects against transient backend glitches: if a run sees fewer than ~70 % of the objects the previous run saw, the delete pass is skipped (so a flaky S3 endpoint doesn't wipe your tree from the cache).

Global tuning (env): FILEX_SYNC_INTERVAL (default 15m) is the fallback cadence, and FILEX_SYNC_WORKERS (default 4) sizes the pool. Per‑storage sync_interval_s takes precedence.

You can watch runs at GET /api/admin/storages/{id}/sync-runs and detect drift with GET /api/admin/storages/{id}/drift.

---

Read‑only mounts

Set read_only: true to expose a storage for browsing/download but block every write (upload, rename, move, delete, share‑drop). Writes return 403 storage is read-only. Useful for archives or a replica you don't want edited.

---

Path validation & errors

Root‑path guard. The API/UI reject a storage whose prefix/root is empty or / with:

ROOT_PATH_FORBIDDEN: storage prefix/path cannot be empty or root '/';
use a sub-folder like 'fileman' or 'data/files'

Always mount a sub‑folder (S3 prefix, or root/path for the others).

Driver errors → HTTP: not found → 404, read-only → 403, unsupported → 501, already exists → 409, anything else → 500. The Test connection endpoint surfaces the raw driver error so you can debug credentials/endpoints before saving.

---

See also

• CONFIGURATION.md — global config/env reference
• RBAC.md — per‑storage and per‑file access control
• INSTALLATION.md · DOCKER.md
